| 主控 CPU | RK3568 |
| 内存 DDR | 2/4/8G Optional |
| 存储 EMMC | 16G/32G/64G Optional |
| 显示屏接口 Screen Port | 10.1寸 1200*1920分辨率 X 310.1 inch 1200*1920 resolution x3 |
| TP 接口 connector | 电容式触摸屏 Capacitive touch screen |
| 双网口 Dual Ethernet ports | 支持Support |
| HDMI | 支持 Support |
| RS485 | 支持Support |
| RS232 | 支持Support |
| CAN | 支持 Support |
| WiFi6 | 可选 Optional |
| 多MICMulti MIC | 支持 Support |
| 其他Others | MIPI摄像头，喇叭，耳机，USB3.0等等MIPI camera, speaker, earphone, USB3.0, etc. |
rk3568 详细参数
- Quad-core Cortex-A55 up to 2.0GHz
- Mali-G52 GPU
- LPDDR4/LPDDR4X/DDR4/DDR3/DDR3L/LPDDR3, ECC
- 4KP60 H.265/H.264/VP9 video decoder
- 1080P60 H.264/H.265 video encoder
- 8M ISP with HDR
- Dual dislplay, LVDS/MIPI-DSI/RGB/eDp/RGB/HDMI2.0/T-CON
- 1x8ch I2S/TDM, 1x8ch PDM, 2x2ch I2S
- USB3.0 x2/SATA3.0 x3/PCIE2.1/QSGMII
- PCIE3.0 1x2Lanes/2x1Lane
