| 主控 CPU | RK3399 |
| 内存 DDR | 4G |
| 存储 EMMC | 8G/16G/32G Optional |
| 显示屏接口 Screen Port | 10.1寸 1200*1920分辨率 10.1 inch 1200*1920 resolution |
| TP 接口 connector | 电容式触摸屏 Capacitive touch screen |
| 双网口 Dual Ethernet ports | 支持Support |
| HDMI | 支持 Support |
| RS485 | 支持 Support |
| RS232 | 支持 Support |
| CAN | 支持 Support |
| WiFi6 | 可选 Optional |
| 多MICMulti MIC | 支持 Support |
| 其他Others | MIPI摄像头，喇叭，耳机，USB3.0等等MIPI camera, speaker, earphone, USB3.0, etc. |
rk3399 详细参数
- Dual-core Cortex-A72 up to 1.8GHz
Quad-core Cortex-A53 up to 1.4GHz - Mali-T860 GPU
- Dual-channel DDR3/DDR3L/LPDDR3/LPDDR4
- 4K UHD H265/H264/VP9
- HDR10/HLG
- H264 encoder
- Dual MIPI CSI and ISP
- Dual USB Type-C and USB 2.0
- HDMI 2.0a with HDCP 2.2
